POWER OUTPUT

>110 Watts into 8 Ohms

POWER OUTPUT

>170 Watts into 4 Ohms

CONTINUOUS CURRENT

>8.5 Amps (sine wave)

MAX CURRENT

+/- 26 Amps, current burst into 0.5 Ohms

OUTPUT IMPEDANCE

<0.05 Ohms – 20Hz to 20KHz

THD

< 0.002%

SNR

>102dB – Line Input

FREQUENCY RESPONSE

10Hz – 100KHz +/- 2dB Line

GAIN

33.3dB (x46) via power amp input

INPUT SENSITIVITY

650mV

CROSSTALK

-80dB at 1Khz

DC OFFEST

< +/-10mV

PRE-AMP INPUTS

5x RCA unbalanced – 1x Balanced XLR

POWER-AMP INPUTS

Input 3 & 4via RCA or XLR

OPTIONAL TUNER

AMBIT FM/AM plug-in module

OPTIONAL DAC

RUBY DAC – USB,SPDIF,Toslink, Bluetooth & FM Tuner

OUTPUTS

2 Pairs

HEADPHONE OUTPUT

Dedicated low impedance amp (<50 Ohms)

IR BUS

Powered output for IR repeater

OPERATING VOLTAGES

110V/230V Switchable

CONSUMPTION (AT IDLE)

<20 Watts (no standby)

CONSUMPTION
(AT FULL POWER)

500 Watts

WEIGHT

9Kgs

DIMENSIONS

430x60x280mm W/H/D
