Input Channels |
Microphone Input |
Electronically Balanced, Discrete Input Configuration |
|
Frequency Response: |
20Hz to 50kHz,+/-3dB |
|
|
Distortion( THD&N) |
＜0.01% At + 4dBu, 1kHz |
|
|
Gain range |
0dB to 50dB (MIC) |
|
|
S/N |
＞100 dB |
|
|
Line Input |
Electronically Balanced |
|
|
Frequency Response: |
20Hz to 50kHz, +/-3dB |
|
|
Distortion(THD&N) |
＜0.01% At + 4dBu, 1kHz |
|
|
Sensitivity range |
20 dBu to -30dBu |
|
|
Impedance |
Microphone Input |
1.4k Ohms |
|
All Other Input |
10k Ohms or Greater |
|
|
All Other Outputs |
120 Ohms |
|
|
MONO Equalization |
High |
±15 dB @12 kHz |
|
MONO Equalization |
High |
±15 dB @12 kHz |
|
Mid |
±12dB@100~8kHz |
|
|
Low |
±15dB@80Hz |
|
|
STEREO Equalization |
High |
±15dB@12kHz |
|
Mid |
±15dB@3kHz |
|
|
Mid |
±15dB@500Hz |
|
|
Low |
±15dB@80Hz |
|
|
MAIN qualization |
7 BAND EQ |
+/-12dB@63,160,400,1K,2.5K,6.3K,16KHz |
|
DSP Section |
A/D & D/A Converters |
24Bit |
|
DSP Resolution |
24Bit |
|
|
Type of effects |
ECHO﹐ECHO+VERB﹐TREMOLO﹐PLATE﹐CHORUS﹐VOCAL﹐ROTARY﹐SMALL ROOM﹐FLANGE+VERB﹐LARGE HALL |
|
|
Presets |
100 |
|
|
Controls |
100-Posistion PUSH Selector |
|
|
CLIP LED |
||
|
MUTE SWITCH(FOOT SWITCH) with LED Indicator |
||
|
Main Mix Section |
Noise (Bus noise) |
Fader 0 dB, Channels muted:-85dBr(ref.:+4dBu) |
|
Fader 0 dB, All Input Channels AssignedAnd Set To UNITY Gain: -80 dBr (ref.: +0dBu) |
||
|
Max output |
+20dBu Unbalanced,1/4"Jacks |
|
|
SUB Sends max out |
+20dBu |
|
|
AUX Sends max out |
+20dBu |
|
|
Power Supply |
Switch Power |
|
|
Dimension (W*D*H) |
531*432*81(mm) |
|
